PRODUCT FEATURES
Features
78 cm gas cooktop with heat deflector plates
• 2 brass gas burner heads comprising:
- Left burner extra high power 4,800 watts
- Right burner extra high power 4,800 watts
• Glass base "Strong Fiber Mesh Tempered Glass"
4-side edge polishing
• Cookware support made from enameled cast iron steel
• Heat deflector plates made from enameled cast iron steel
• Electronic automatic gas ignition system using:
- Size D 1.5 Volt flashlight batteries
• Equipped with safety valve system
TECHNICAL DATA
Technical Specifications
• Product dimensions: Width x Depth: 78.0 x 45.0 cm.
• Cabinet cutout dimensions: Width x Depth: 68.0 x 35.0 cm.
• Must be used with low pressure regulator heads (37 millibars) only.
Product Information
• Product weight: 12.80 kg.
• Product weight with packaging: 14.90 kg.
• Box dimensions: 50.0 (depth) x 87.0 (width) x 21.0 (height) cm.
Touch control canopy range hood 90 cm size
• Extraction motor 400 watts
• Maximum total air extraction 1,250 m³/hour
• Maximum net extraction 1,000 m³/hour
• Touch control operation system
• 4-level motor power adjustment
• Stainless steel oil filter and trap
• 1 LED bar light fixture (1x7 watts)
• Automatic timer shutdown 3 minutes and 7 minutes
• Compatible with external air circulation system
**Can be installed with internal circulation system (Optional accessory: Carbon filter sold separately)
TECHNICAL DATA
Technical Specifications
• Product dimensions: Width x Depth x Height: 89.8 x 45.0 x 42.5 - 81.5 cm.
• Power consumption: 407 watts, 220 volts, 50 Hz.
• Uses ø 150 mm air duct
Product Information
• Product weight: 18.00 kg.
• Product weight with packaging: 22.00 kg.
• Box dimensions: 96.0 (depth) x 54.0 (width) x 60.0 (height) cm.
