下拉式壁挂柜套装 - Pull-down baske
产品详情
材料: 钢制框架, 304 不锈钢篮筐
颜色: 框架浅灰色, 篮筐不锈钢抛光
承重能力: 每层 6 公斤
3 级承重调节
柜体内部最小高度: 700 毫米
柜体内部最小深度: 290 毫米
柜体宽度: 800 和 900 毫米
柜体宽度 800 毫米的尺寸 (宽 x 深 x 高): 763X265x546 毫米
柜体宽度 900 毫米的尺寸 (宽 x 深 x 高): 863X265x546 毫米
包含内容
下拉式框架套装配备缓冲关闭系统 1 套, 篮筐 2 个, 安装螺钉套装 1 套
Features
Material: Steel frame, stainless steel 304 basket
Finish: Frame light grey, basket polished
Load capacity: 6 kg per shelf
3 levels of weight adjustment
Min. internal cabinet height: 700 mm
Min. internal cabinet depth: 290 mm
Cabinet width: 800 and 900 mm
Dim. for Cabinet width 800 mm (WxDxH): 763X265x546 mm
Dim. for Cabinet width 900 mm (WxDxH): 863X265x546 mm
Supplied with
Set components complete with 1 set pull down frame with soft close
mechanism, 2 baskets, 1 set fixing screws
