HAFELE Condo Solutions Set - 11
Induction Cooktop
Material: Ceramic glass, 3-burner induction cooktop
Color: Black
Product Size (W x D x H): 590 x 520 x 60 mm
Installation Size (W x D): 565 x 495 mm
Weight: 9.51 kg
Packaging: 1 unit
Usage: For kitchen installation
Caution: Do not use chemical cleaners
Warranty: 3 years
Features
• Front left Ø210 mm (Power 2,300/2,600 Watts) - Poweboost
• Rear left Ø160 mm (Power 1,200/1,500 Watts) - Poweboost
• Right side Ø320 mm (Power 2,300/3,000 Watts) - Poweboost
• Touch control system
• 9 heat levels
• Child lock safety system
• Auto-off timer function 1-99 minutes
• Automatic cookware detection
• Automatic shutdown function when cooktop is left on too long; Residual heat display function
• Total power consumption: 7,100 Watts
• Operating voltage: 220-240 V, 50/60 Hz
Wall-mounted Range Hood
Material: Stainless steel and glass
Color: Stainless steel
Size (W x D x H): 600 x 500 x 50/70 mm (390-770 mm)
Weight: 17.60 kg
Packaging: 1 piece
Usage: For kitchen installation
Caution: Avoid impact
Recommendation: Read instructions in manual before use
Warranty: 3 years
Material: Stainless steel and glass
Front panel: Black color
Suction power: 1,400 m³/h
Touch control with LED display
3 suction levels
LED lighting system 2 x 0.5 Watts
Stainless steel oil filter 2 pieces
Carbon filter
Plastic water collection cup
Exhaust duct diameter 150 mm
Total electrical power consumption: 380 Watts
Operating voltage: 220-240 V, 50 Hz
Maximum noise level: 71 dB
Material: Stainless steel with glass
Front panel: Black color
Suction power: 1,400 m3/h
Touch control with LED display
3-speed levels
Lighting: LED light 2x0.5 W
Baffle filter 2 pcs.
Carbon filter
Plastic oil cup
Flexible duct Ø150 mm
Electrical connection rating: 380 W
Voltage: 220-240 V, 50 Hz
Max noise level: 71 db (A)
