CONDO SOLUTION SET 2
Includes
1. HAFELE Ceramic Glass Electric Cooktop: Series 5: 495.06.059
2. HAFELE Slim Line Range Hood: Series 5 (GALE): 495.38.324
Product Details
1. HAFELE Ceramic Glass Electric Cooktop: Series 5: 495.06.059
• Material: Ceramic glass
• Color: Black
• Size (W x D x H): 290 x 520 x 53 mm
• Packaging: 1 unit
• Installation: Built In
• Caution: Avoid impact
• Recommendation: Should be installed by a trained technician
• 3-year warranty
• 2 cooking zones
• Front right Ø165 mm (1,200 W)
• Rear right Ø200 mm (1,800 W)
• Touch control
• 9-stage power setting
• Safety lock for child protection
• Timer function 1-99 minutes, over-heating protection system
• Operating time limitation shutdown system
• Residual heat indicator function
• Total power consumption: 3,000 W
• Operating voltage: 220-240 V, 50/60 Hz
Material: Ceramic glass top 2 Cooking zones
Front Ø165 mm (1,200 W)
Rear Ø200 mm (1,800 W)
Touch control
9 stage power setting
Safety lock
Timer 1-99 minutes
Over-heating protection
Operating time limitation
Residual heat indicator
Electrical connection rating: 3,000 W
Voltage: 220-240 V, 50/60 Hz
2. HAFELE Slim Line Range Hood: Series 5 (GALE) 495.38.324
• Material: Stainless steel
• Color: Stainless steel
• Product size (W x D x H): 595 x 296 x 225 mm
• Installation size (W x D x H): 549 x 281 x 180 mm
• Packaging: 1 unit
• Installation: For kitchen installation
• Caution: Should be installed with care
• Recommendation: Should be installed by a trained technician
• 3-year warranty
• Maximum suction power: 750 m³/h
• Lighting bulbs 40 W, 2 units
• Push button switch for light on/off
• Adjustable air speed: 2 levels
• On/off with slide-in and slide-out operation
• Technical Data
• Operating voltage: 220 V 50/60 Hz
• 3-pin plug with system
Material: Stainless steel
Colour of panel: Stainless steel or black
Suction power: 750 m3/h
Rocker push button
2 Speed levels
Lighting: LED 2x2 W
Aluminium grease filter 2 pcs.
Charcoal filter 2 pcs.
Flexible duct Ø150 mm (order separately)
Ventilation size 150 mm (incl. adapter 150–100 mm)
Electrical connection rating: 134 W
Voltage: 220-240 V, 50/60 Hz
Max. noise level: 61 db(A)
